HETTICH ACTRO 5D UNDERMOUNT RUNNER – FULL EXTENSION WITH SILENT SYSTEM Precision as a matter of principle: thanks to its ball bearing principle, a Quadro runner guarantees lasting top performance and the last word in convenience for drawers. Elegantly concealed underneath the drawer bottom panel. Load Capacity – 40 Kgs Features: Drawer runner for combining with wooden drawer Full extension runner with integrated tilt adjustment and radial adjustment Slide on installation with 2D catches for tool-less height and side adjustment Optional: depth adjustment Integrated Adjustments all toolless: height adjustment up to 3 mm, side adjustment up to /- 1.5 mm, tilt adjustment up to 4 mm and radial adjustment up to /- 1.5 mm and depth adjustment up to /- 2 mm Suitable for drawers with a side profile thickness of up to 16 mm Optional: Push to open Silent opening system Optional: pull-out shelf support / pull-out shelf locating catch Load capacity to EN 15338, Level 3 Galvanised steel Sizes available from 350mm-550mm Price includes LH & RH Slides L&R Clips Download Installation Instruction Sheet
